2027
Chevrolet
Magellan by Collins
6.6L V 8 Cyl
1GB3GRB77T1279036
Vehicle info
Stock |
97491 |
VIN |
1GB3GRB77T1279036 |
Dealer |
Don Brown Bus Sales |
Type |
New |
Year |
2027 |
Make |
Chevrolet |
Model |
Magellan by Collins |
Dealer Certified |
No |
Certified |
No |
Trim |
SRW |
Model Number |
CG33503 |
Body |
Cutaway |
Body Style |
Specialty |
Style |
3500 Van 139" |
Transmission |
Automatic |
Transmission Description |
8-Speed Automatic |
Transmission Speed |
8 |
Doors |
2 |
Cylinders |
8 |
Displacement |
6.6L |
Block Type |
V |
Aspiration Type |
Electronic Fuel Injection |
Description |
Gas V8 6.6L/ |
Drivetrain |
RWD |
Fuel Type |
Gasoline Fuel |
Wheelbase Code |
139 |
Exterior Color |
Blue |
Interior Color |
SOLD - NEW CANNAN CO SCHOOLS |
Portions of the data provided are © 2026 Autodata, Inc. dba ChromeData
EQUIPMENT DETAIL
Exterior
- Bumper, front painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
- Flasher, heavy duty light emitting diode (LED)
- Glass, Solar-Ray light-tinted, all windows
- Grille, Black composite (Not available with (ZR7) Chrome Appearance Package.)
- Headlamps, dual halogen composite
- License plate kit, front
- Mirrors, outside delete (Not available with (5Q7) Upfitter option Blank Sail Panel Delete when ordered with (YF2) Ambulance Package.)
- Tires, front LT245/75R16E all-season, blackwall (Requires (R04) single rear wheel configuration. Jack and spare tire equipment bracket are not included.)
- Tires, rear LT245/75R16E all-season, blackwall (Requires (R04) single rear wheel configuration. Jack and spare tire equipment bracket are not included.)
- Wheel configuration, rear, single (Not available with (C7N) 12,300 lbs. (5579 kg.) GVWR.)
- Wheels, 4 - 16" x 6.5" (40.6 cm x 16.5 cm), 8-lug painted steel, heavy-duty (Only available with (R04) single rear wheel configuration.)
- Wipers, front intermittent wet-arm with pulse washers
Installed
- ENGINE, 6.6L V8 with Direct Injection and Variable Valve Timing, gasoline, (401 hp [299 kW] @ 5200 rpm, 464 lb-ft of torque [629 N-m] @ 4000 rpm) (Includes external oil cooler.
Interior
- Air conditioning, single-zone manual
- Assist handles, driver and right-front passenger
- Audio system, AM/FM stereo with MP3 player seek-and-scan, digital clock, TheftLock, random select, auxiliary jack and 2 front door speakers
- Cup holders, 3 on the engine console cover
- Driver Information Center includes fuel range, average speed, oil life, fuel used, ice warning, engine hours, average fuel economy, tachometer and maintenance reminders
- Floor covering, Black rubberized-vinyl front
- Headliner, cloth, over driver and passenger
- Heater and defogger with front and side window defoggers
- Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure
- Lighting, interior with dome light and door handle-activated switches
- Mirror, inside rearview includes Rear Vision Camera display (Included and only available with (UVC) Rear Vision Camera.)
- Oil life monitor
- Power outlet, 120-volt
- Power outlets 2 auxiliary on engine console cover with covers, 12-volt
- Seating arrangement, driver and front passenger high-back bucket includes head restraints and vinyl or cloth trim (Not available with (AJ3) driver-side only frontal airbag.)
- Seats, front bucket with vinyl trim and head restraints includes inboard armrests (Requires (**W) trim. Not available with (ZP0) delete driver and passenger seats. Includes only driver high-back bucket seat with vinyl trim when ordered with (ZX1) driver-only high-back bucket seating arrangement.)
- Theft-deterrent system, vehicle, PASS-Key III
- Visors, driver and front passenger, cloth, padded
- Warning tones, headlamp on and key-in-ignition
Mechanical
- Alternator, 150 amps
- Battery, 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power
- Body, standard
- Brakes, 4-wheel antilock, 4-wheel disc
- Cooling, external engine oil cooler
- Emission System, 8.5K-10K GVW (Requires (FE9) Federal emissions requirements, (YF5) California state emissions requirements or (NE1) Colorado, Connecticut, Delaware, Maine, Maryland, Massachusetts, Minnesota, Nevada, New Jersey, New York, Oregon, Pennsylvania, Rhode Island, Vermont or Washington state emissions requirements.)
- Engine, 4.3L V6 with Direct Injection and Variable Valve Timing, includes aluminum block construction (276 hp [206 kW] @ 5200 rpm, 298 lb-ft of torque [404 Nm] @ 3900 rpm) (Requires (C4M) 9900 lbs. (4490 kg) GVWR. Not available with (YF2) Ambulance Package, (YF1) RV Package, (ANC) Shuttle Bus Package, (JFF) 10,100 lb. (4581 kg) GVWR or (C7N) 12,300 lbs. (5579 kg) GVWR. Includes external engine oil cooler. Reference the Engine/Axle page for availability.)
- Exhaust, aluminized stainless-steel muffler and tailpipe
- Frame, ladder-type
- Fuel tank capacity, mid-frame and approximately 32 gallons (121.1L)
- GVWR, 9900 lbs. (4490 kg) (Includes (R04) single rear wheel configuration. Not available with (R05) dual rear wheel combination. Reference the Engine/Axle page for availability.)
- Incomplete vehicle certification
- Rear axle, 3.42 ratio (Requires (R04) single rear wheel configuration.)
- Rear wheel drive
- Steering, power
- Suspension, front independent with coil springs and stabilizer bar
- Suspension, rear hypoid drive axle with multi-leaf springs
- Tow/haul mode selector, instrument panel-mounted
- Transmission, 8-speed automatic electronically controlled with overdrive and tow/haul mode. Includes Cruise Grade Braking, Powertrain Grade Braking and Tap-Up/Tap-Down Driver Shift Control (Reference the Engine/Axle page availability.)
Safety
- Airbag deactivation switch, frontal passenger-side (Not available with (AJ3) frontal, driver-side only airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
- Airbags, frontal, front driver and right front passenger includes passenger-side frontal airbag deactivation switch (Included with (ZX2) driver and right-front passenger high-back bucket seats or (ZP0) driver and passenger temporary seats. Not available with (ZX1) driver only high-back bucket seat or (AJ3) driver-side only frontal airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
- Airbags, seat-mounted side-impact for driver and right-front passenger and roof-rail mounted head-curtain side-impact (Included with (C4M) 9900 lb. (4490 kg) GVWR. Available on (JFF) 10100 lb. (4581 kg) GVWR, (C7N) 12300 lb. (5579 kg) GVWR, and (C7I) 14200 lb. (6441 kg) GVWR. Not available with (B3D) School Bus Package, (ANC) Shuttle Bus Package, (YF1) RV Package, and (9T7) right-hand door delete. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
- Brake/transmission shift interlock for automatic transmissions
- Daytime Running Lamps
- Hill Start Assist
- OnStar and Chevrolet connected services capable (Currently not available to order. Not available with (YF1) RV Package or (YF2) Ambulance Package. Included with (FDR) Fleet Daily Rental order types. Terms and limitations apply. See onstar.com or dealer for details.)
- OnStar Basics (OnStar Fleet Basics for Fleet) Drive confidently with core OnStar services including remote commands, built-in voice assistance, real-time traffic and navigation, and Automatic Crash Response to help if you're in need. (Requires (UE1) OnStar. OnStar Basics includes remote commands, Navigation, Voice Assistance, and Automatic Crash Response, for eligible vehicles with compatible software. OnStar Basics is standard for 8 years; OnStar plan, working electrical system, cell reception and GPS signal required. OnStar links to emergency services. Service coverage varies with conditions and location. Service availability, features and functionality vary by device and software version. See onstar.com for details and limitations.)
- Rear Vision Camera camera and cable shipped loose (Display included with (DRJ) inside rearview mirror.)
- StabiliTrak, traction assistance and vehicle stability enhancement system
- Tire Pressure Monitor System (does not monitor spare tires) (Required with (C4M) 9900 lbs. (4490 kg) GVWR and (R04) single rear 4 - 16" x 6.5" (40.6 cm x 16.5 cm) wheels.)
